| Product Specifications |
Voltage: AC90-240V 50HZ/60HZ
Power: 1000W
Light source: 50*20W ultra-bright RGBW LED
Lifespan: 50,000 hours
Color: Red, green, blue, white, multiple colors, infinitely changeable
Lamp control: RGBW control
Vertical direction: 220° (16 bit precision scanning)
Y-axis adopts high-speed silent 60 three-phase thickened motor drive, making the operation faster and smoother. It can automatically return to its position after a misoperation, and the vertical speed is adjustable; Y-axis rotation function and reverse function; photoelectromagnetic encoding high-precision positioning
Electronic strobe, 0.3~25 times/second
Dimming: Electronic dimming 0~100% linear adjustment, with gamma curve dimming frequency 1.2K~25K adjustable, with macro instruction dimming linear, stable, smooth and flicker-free, using stable constant current drive and power supply, suitable for video shooting
Control mode: 11CH (standard) 1 channel Channel control mode, standard DMX512 protocol, RDM protocol
Power connection method: power input and output, maximum number of connections @2 units 230V, 1 unit 120V
Signal connection method: DMX512 input and output, support network protocol Artnet
Display function: LCD touch screen, Chinese and English bilingual menu, sensor fault display, temperature display
Cooling system: high-conductivity light aluminum radiator, fan intelligent monitoring technology automatically adjusts the fan speed according to the temperature of the lamp, built-in overheat protection intelligent system/intelligent temperature and noise balance module
Protection level: IP65 |
